Specifications
Wall Height and Sizing Information:
There are three sizes of 8700 hardware available. Always install the largest size that suits your caravan wall height.
Ultra Short:
Minimum wall height required – 1475 mm
Standard (This Kit):
Minimum wall height required – 1620 mm
Tall:
Minimum wall height required – 1925 mm
ARE You Replacing Existing Hardware ?
To determine your current hardware size, measure the Main Arm length:
• Ultra Short Main Arm – 1350 mm
• Standard (This Kit) – 1550 mm
• Tall – 1855 mm
If your existing main arm measures approximately 1550 mm, this listing is the correct replacement size.
Specifications:
Brand: Dometic
Model: 878HS-WHT
Part Number: 9600027146
Finish: White Powder Coated
Installation Type: Flat wall only
Minimum Wall Height Required: 1620 mm
Compatibility: 8700 Awnings / 8300, 8500 & 9000 Barrels
Replaces Previous Models: 8483004.402U / 8271003.402U
Individual Component Dimensions:
SMain Arm Length: 1550 mm
Inner Arm Length: 1450 mm
Main Rafter Length: 1370 mm
Secondary Rafter Length: 1130 mm
FAQ
Q: Is This for both the Right and Left hand (complete kit) ?
Yes, this is for both.
Q: Can i buy an individual Left or Right hand?
No, this is only sold as a complete kit.
Q: Will this suit my Dometic 8300 or 8500 awning barrel?
Yes. This hardware kit is compatible with existing 8300, 8500 and 9000 awning barrels.
Q: How do I know if I need Standard size?
Measure your existing main arm. If it measures approximately 1550 mm, this is the correct size. Also ensure your caravan wall height is at least 1620 mm.
Q: Can this be installed on a curved wall?
No. This hardware kit is designed for flat wall installations only.
Are the wall bracekts, bottom foot bracket and screws included?
Yes, This is a complete kit.
